Application:
It has widely used, especially for the liquid has the impurities.
Features:
The valve seat (body sealing ring) using inflatable structure, to ensure the sealing ring has no contact, thus eliminating the abrasion between the sealing ring, reducing the opening torque. Effective compensation for the abrasion of the sealing ring by the medium, which extends the life of the valve.
Structure diagram:
Nominal diameter（mm）：DN200～DN5000
Nominal pressure（Ｍpa）：0.1～4.0MPA
Suitable temperature：≤150℃
Suitable medium: smoke, air, gas, natural gas, etc.
Type of sealing : soft sealing, hard sealing.
Type of control : manual, electric, pneumatic, hydraulic,etc.
Material:carbon steel, stainless steel, alloy steel.
Standard: GB, BS, ASME, JIS, DIN, EN, ISO and other country, also can be produced according to user’s requirements.
