Application:
This valve is suitable for blast furnace hot stove system to cut off medium.
Features:
It is whole welded structure, according to the requirements of the working conditions.Some are fully lined with high temperature resistant materials.In addition to the lining of high-temperature materials, but also the use of circulating water-cooled structure.
Structure diagram:
Nominal diameter（mm）：DN500～DN3000
Nominal pressure（Ｍpa）：≤0.6MPA
Cooling water pressure:0.2～0.6MPA
Suitable temperature：≤1450℃
Suitable medium: hot wind,etc.
Type of sealing : hard sealing.
Type of control : manual ,electric, pneumatic,etc.
Material of main part: carbon steel, stainless steel ,dual phase steel,etc.
Standard: GB, BS, ASME, JIS, DIN, EN, ISO and other country, also can be produced according to user’s requirements.
